KFI Winch

KFI WINCH LINE UP

Each KFI winch kit features quality cast aluminum and durable steel components and comes with a full complement of accessories including Premimum Roller Fairlead, a fairlead bracket for mounting to trailers or other non-ATV applications, Handlebar Mini-Rocker Switch, 14' corded hand held remote on ATV and UTV series, all of the hardware to mount your winch to a model specific ATV/UTV winch mount, a Heavy-Duty Electric Contactor that protects the electrical system and detailed installation instructions. An ATV/UTV specific winch mount must be purchased separetly. They are also backed by a KFI 1-Year Limited Warranty.

STC17:

This compact 1700lb Sport Trail Series winch features water resistant seals to keep the elements out, a standard 4-hole mounting design and a heavy duty 3-stage planetart gear system with all metal enclosures.

• Rated Line Pull:1700lbs
• Motor: 12V DC, 0.58hp permanent magnet
• Gear Ratio: 103:1
• Cable: 5/32" D x 49'L
• Winch Dimensions: 10.67"L x 3.85" D x 4.58"H
• Mounting Bolt Pattern:3.00" x 4.875" (4-Hole)
• Winch Weight: 19.8lbs

A2500-RL:

This 2500lb ATV Series Winch features Water Resistant seals to keep the elements out, a standard 4-hole mounting design and a heavy-duty all metal turn clutch

• Rated Line Pull:2500lbs
• Motor: 12V DC, 1hp permanent magnet
• Gear Ratio: 171:1
• Cable:3/16"D x 45.9'L
• Winch Dimensions: 12.67"L x 4.06"D x 4.2"H
• Mounting Bolt Pattern: 3.00" x 4.875" (4-Hole)
• Winch Weight: 24.8lbs

A3000:

This 3000lb AtV Series winch features Water Resistant seals to keep the elements out, a standard 4-hole mounting design and a heavy-duty all metal turn clutch.

• Rated Line Pull:3000lbs
• Motor:12V DC, 1.5hp permanent magnet
• Gear Ratio:171:1
• Cable: 3/16" D x 45.9'L
• Winch Dimensions: 12.67"L x 4.06"D x 4.2"H
• Mounting Bolt Pattern:3.00" x 4.875" (4-Hole)
• Winch Weight: 24.8lbs
• Hand-held remote included

U4500/U4500W:

This 4500lb UTV Series winch features Water Resistant seals to keep the elements out, a standard 4-hole mounting design and a heavy duty all metal turn clutch. Available in standard or wide.

• Rated Line Pull:4500lbs
• Motor: 12V DC, 1.7hp permanent magnet
• Gear Ratio: 166:1
• Standard Cable: 15/64"D x 38'L
• Wide Cable: 15/64"D x 52'L
• Standard Winch Dimensions:14.6"L x 4.55"D x 4.82"H
• Wide Winch Dimensions:16.36"L x 4.55"D x 5"H
• Standard Mounting Bolt Pattern: 3.00" x 4.875" (4-Hole)
• Wide Mounting Bolt Pattern:3.00" x 6.60" (4-Hole)
• Standard Winch Weight: 35.5lbs
• Wide Winch Weight: 35.5lbs
• Hand-held remote included.
